Polyester Powder Coating is a series of polyester-based coatings that utilize either TGIC or TGIC-free formulas. Suitable for both interior and exterior applications, these coatings deliver excellent light fastness and weather resistance with just a single coat on various substrates. The series comes in a wide array of colors, gloss levels, and textures.
Polyester powder coatings are a series of polyester-based powder coatings formulated with TGIC (triglycidyl isocyanurate) or TGIC-free formulations. This powder coating requires heating (baking) after application to complete the curing process. Under heat, the resin molecules in the coating undergo cross-linking reactions, forming a three-dimensional network of insoluble, infusible, and tough paint film. It exhibits excellent characteristics including high hardness, good adhesion, chemical resistance, abrasion resistance, and heat resistance.
The polyester powder coating series is specifically designed for outdoor or indoor applications, delivering outstanding lightfastness and weather resistance with a single coat on various substrates. Our polyester powder coating series offers a wide range of color options, varying gloss levels, and textured finishes, all customizable to meet your specific requirements.
Main Properties | Excellent UV resistance for exterior application. |
Excellent heat resistance | |
Powder Characteristic | |
Chemistry | Polyester TGIC or TGIC free |
Particle Size | D[V,0.5]: 36-40µm Suitable for electrostatic spraying |
Specific Gravity | 1.2-1.7g/cm3 up to colors |
Coverage(@60μm) | 9-12㎡/kg |
Curing | 200℃/10minutes(Substrate Temperature) |
Film Thickness | 60-80µm |
Pencil Hardness | 1H |
Impact Resistance | 50kgcm |
Adhesion | 100% |
Color Difference | ΔE<0.5 |
Color and Texture | Customizable, suitable for all colors and textures. |
Excellent Weather Resistance and UV Stability
Superior Mechanical Properties
Environmentally Friendly and Pollution-Free
Excellent Adhesion
Wide Range of Colors and Textures
High Temperature Resistance
Stain Resistance and Easy Cleaning
Construction and Decoration
Automotive Parts
Agricultural machinery
Industrial Equipment and Machinery
Household Appliances
Outdoor Facilities and Metal Structures
Electrical equipment
Fencing
Solar Equipment
Lawn & garden equipment
Sports & recreation equipment
Cycles & motorbike details
HVAC units
Signs
25 kg/box, dry ventilation conditions below 30℃.
Feel free to contact us for customized products' specification and package
